Data Center SSD

Micron 9550 NVMe SSD

PCIe Gen5 data center SSD positioned as the world's fastest, up to 30.72 TB

Mass ProductionGen5FlagshipMicron

Micron · U.2 / E1.S / E3.S

Flagship Gen5 data center SSD with 14 GB/s reads, 3.3M IOPS, OCP 2.0 support, and capacities to 30.72 TB.

Interface
PCIe 5.0
Form factor
U.2 / E1.S / E3.S
Capacities
3.2 TB6.4 TB7.68 TB12.8 TB15.36 TB25.6 TB30.72 TB
Enquire about this product Datasheet — coming soon

Product briefing

On the record.

The Micron 9550 is the company's flagship PCIe Gen5 data center SSD, launched with the positioning of world's fastest data center SSD: up to 14 GB/s sequential read and 3.3 million random read IOPS from a vertically integrated Micron controller, DRAM, and 232-layer TLC NAND stack.

Built for AI storage pipelines, the 9550 posts leading results in GPU-direct data loading and graph neural network training while drawing less power per transfer than competing Gen5 drives. Security includes SPDM 1.2 attestation and OCP 2.0 datacenter specification support; capacities reach 30.72 TB across U.2, E1.S, and E3.S form factors.

Data sheet

Specifications

Specifications for Micron 9550 NVMe SSD
InterfacePCIe 5.0 x4, NVMe 2.0
Form FactorU.2, E1.S, E3.S
Capacities3.2 TB to 30.72 TB
Sequential ReadUp to 14,000 MB/s
Sequential WriteUp to 10,000 MB/s
Random ReadUp to 3,300K IOPS
NAND TypeMicron 232-layer 3D TLC
Endurance1 DWPD (PRO) / 3 DWPD (MAX)
SecuritySPDM 1.2, TCG Opal 2.01, OCP 2.0
MTBF2.5M hours
